| Brand | Hikvision | | Model | DS-K1T343MX |
| Operating system | Linux |
| Capacity | Up to 1.500 faces and 3.000 cards/passwords |
| Records | 150.000 registers |
| Identification modes | Facial recognition, RFID card, PIN and/or combinations |
| Proximity card | MF (13.56 MHz) |
| Screen | 4.3" TFT color touch screen LCD |
| Screen resolution | 480 x 272 |
| Camera | 2 Mpx with dual sensor for face recognition |
| Facial recognition verification time | < 0.2 sec |
| Facial recognition accuracy | > 99% |
| Facial recognition distance | 0.3 m to 1.5 m |
| Communication | TCP/IP, USB, RS485 and Wiegand |
| Integrated controller | Wiegand 26/34, door sensor, pushbutton and relay |
| Alarms | Tamper |
| Audio | Bidirectional audio |
| Special functions | Operation as a video door entry system |
| Software | iVMS-4200 / iVMS-4200 AC |
| Mobile application | Hik-Connect |
| Power | DC 12 V / 1 A max. |
| Degree of protection | Valid for interior |
| Temp. operation | -10º C ~ +40º C |
| Dimensions | 118.4 (W) x 118.4 (H) x 21.8 (D) mm |
| Weight | 230 g |
