| Code | TOW-L180H-kit |
| Main power supply | AC100-240 + Solar Panel |
| Outdoor cabinet | Fiberglass IP68 (ventilation system IP54)) |
| Lithium battery LiFePo4 | 1728 Wh |
| Battery voltage | 28v |
| Full recharge | Fast charge 10,7A/310Wh 5,5h |
| Maximum load | 15A |
| Charging algorithm | MPPT BUCK / BOOST |
| Photovoltaic Max Power | 800Wp (54-72 cells) |
| Rated Voltage Photovoltaics | 36V (max 54V open circuit) |
| Panel connectors MC4 | 4 |
| Battery cycles (DOD 80%)) | 2000 |
| Connectors IP68 RJ45 | 4 |
| Integrated display | Programmable + instantaneous volt control |
| Magnetothermic Overvoltage Arrester | Yes |
| Surge arrester | - |
| Battery protection fuse | 32A extra-fast SPD type2 (20kA) |
| Door opening alarm | Yes |
| Door lock | Yes |
| Network presence check | Yes |
| Low battery contact | Yes |
| Internal temperature control | Yes |
| automatic ventilation | Yes |
| Dimensions (H. x An. x Pr.) | 500 x 430 x 210 |
| Box Weight Kg (with Mounting Kit) | 24,9 (28,9) |
| External environmental sensors | PM Integrated 1-2.5-4-10, Temperature, Humidity, Pressure |
| GSM Cloud Modem M2M | Integrated with prepaid and rechargeable SIM from 500MB |
| IoT remote control and alarms | Cloud-based data management software included |
| Support for pole installation | Included (for diameters from 50 to 140 mm) |
| Large box version 434 x 504 x 210 | - |
| Street floor box version | L180S T |
