High efficiency solar charge controller (minimum 96%), can operate with any type of solar panels regardless of battery voltage.
The charging profile is optimized for LiFePO4, batteries, ensuring maximum efficiency and safety.
Modern MPPT (maximum power point tracking) algorithm to achieve maximum efficiencies even with partial or poor insolation.
| Code | TOW-L75S |
| Main power supply | Solar panel |
| Outdoor cabinet | Fiberglass IP68 (ventilation system IP54)) |
| Lithium battery LiFePo4 | 864 Wh |
| Battery voltage | 14V |
| Full recharge | - |
| Maximum load | 15A |
| Charging algorithm | MPPT BUCK / BOOST |
| Photovoltaic Max Power | 800Wp (54-72 cells) |
| Rated Voltage Photovoltaics | 36V (max 54V open circuit) |
| Panel connectors MC4 | 2 |
| Battery cycles (DOD 80%)) | 2000 |
| Connectors IP68 RJ45 | 4 |
| Integrated display | Programmable + instantaneous volt control |
| Magnetothermic Overvoltage Arrester | - |
| Surge arrester | - |
| Battery protection fuse | 20A extra-fast |
| Door opening alarm | Yes |
| Door lock | Yes |
| Network presence check | Yes |
| Low battery contact | Yes |
| Internal temperature control | Yes |
| automatic ventilation | Yes |
| Dimensions (H. x An. x Pr.) | 425 x 325 x 180 |
| Box Weight Kg (with Mounting Kit) | 15,5 (19,0) |
| External environmental sensors | PM Integrated 1-2.5-4-10, Temperature, Humidity, Pressure |
| GSM Cloud Modem M2M | Integrated with prepaid and rechargeable SIM from 500MB |
| IoT remote control and alarms | Cloud-based data management software included |
| Support for pole installation | Included (for diameters from 50 to 140 mm) |
| Large box version 434 x 504 x 210 | L75S XL |
| Street floor box version | L75S T |
