| Brand |
Safire Smart |
| Range |
E1 with Artificial Intelligence |
| Image sensor |
1/2.7“ Progressive Scan CMOS |
| Resolution |
4 Megapixel (2560x1440) |
| Main Stream |
2560×1440,1920×1080,1280×960,1280×720 |
| Sub stream |
704x576, 640x480, 352x288 |
| Third Stream |
1920×1080, 1280×960, 1280×720, 704×576, 640×480, 352×288 |
| Video Bit rate |
64Kbps ~ 8Mbps |
| Minimum illumination |
Colour: 0.01 Lux @(F1.6, AGC ON), 0 Lux with IR |
| IR LED |
160m (850nm) |
| Compression |
H.265+/ H.265 / H.264+/ H.264 |
| Optical Zoom |
25X |
| Digital Zoom |
16X |
| Lens |
4.8 - 120 mm |
| FOV |
H: 55º - 2.4º / V: 33º - 1.4º / D: 61.5º - 2.8º |
| Range performance |
W: 96 m (D), 38 m (O), 19 m (R), 10 m (I) T: 2200 m (D), 873 m (O), 440 m (R), 220 m (I) |
| Electronic shutter |
1/1s~1/10,000s |
| Day / Night |
Removable mechanical ICR filter |
| Image improvements |
BLC, HLC, WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI |
| Advanced functions |
Artificial intelligence based on human-vehicle classification on: Area Intrusion, Line Crossing, Entry Region, Exit Region.
Face detection with face capture of up to 15 faces at a time. Smart tracking after face detection. |
| Intelligent Autotracking |
Intelligent tracking of humans and vehicles |
| Pan/Tilt Range |
Horizontal: 360°, Vertical: -10°~90° auto flip |
| Manual speed |
Horizontal: 0.1° ~ 200°/sec, Vertical: 0.1° ~200°/s |
| Speed between Presets |
Horizontal: 240° /s, Vertical: 240° /s |
| Preset positions |
360 Preset, 8 Tours, 4 Patrols |
| Internal memory |
MicroSD card, Max 256 GB |
| Audio |
1 Input / 1 Output |
| Audio Compression |
G.711 A/U |
| Audio bit rate |
64 Kbps |
| Alarms |
1 Input / 1 Relay |
| PTZ Control |
Through network access |
| Network interface |
Ethernet 10 / 100M BaseT |
| Remote access |
Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability |
ONVIF, PSIA, CGI |
| Power |
DC 12 V / 3A, PoE IEEE802.3at |
| Temp. operation |
-40º C ~ +60º C |
| Degree of protection |
IP66 / Surges 6000V |
| Dimensions (without bracket) |
268 mm (H) x 173(Ø) mm |
| Weight (without bracket) |
2100 g |
