| Brand | HIKVISION |
| Range | Value |
| Image sensor | 1/2.7" Progressive Scan CMOS |
| Maximum resolution | 5 Megapixel (2560x1920) |
| Main Stream rate | 20 fps (2560x1920), 25 fps (2560x1440, 1920×1080, 1280×720) |
| Extra Stream rate | 25 fps (1280×720, 640×480, 640×360) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 16 Mbps |
| Lens | Motorized varifocal 2.8~12 mm (H: 96~29°, V: 69~22°, D: 131~37°) |
| Minimum illumination | Colour: 0.005 Lux @(F1.6, AGC ON) Black and White: 0 Lux with Infrared |
| Infrared lighting | EXIR IR LEDs (30 m) |
| Day / Night | Removable mechanical ICR filter |
| Image improvements | WDR (120 dB), BLC, 3D-DNR, AWB, AGC, ROI, Mirror effect, Privacy masking |
| Motion Detection | Yes |
| Internal memory | Slot for micro SD card up to 256 GB |
| Network interface | Ethernet 10/100M BaseT |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power | DC 12 V / 750 mA / 9 W max. / IEEE802.3af PoE |
| Degree of protection | Weatherproof IP67 |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | Ø 129.4 mm × 116.4 mm |
| Base dimensions | Ø base 129.4 mm / Ø entre tornillos 112.4 mm / 3 tornillos |
| Weight | 590 g |
